A tracked dumper measured for restricted access: 715 mm narrow clearance width, 800 mm overall frame, 500 kg payload. The steel skip tips hydraulically on a single lever, and the rubber tracks keep ground pressure low.
Includes free delivery to the UK mainland.
New and unregistered. Ships direct from our supplier.
Added to your basket. View basket
Buy now takes you straight to checkout with this machine in your basket.
Measured detail
Measured at the narrowest point. A standard UK back door is 813 mm, which leaves about 98 mm to spare.
The steel skip tips hydraulically, so unloading needs a lever, not a shovel.
Low ground pressure on turf and grip on slopes.
About twelve 40 kg barrow loads, carried in one trip.
Throttle and tip lever grouped on the handlebar.
A loading height you shovel into rather than lift over.
Full specification
| Model | MachEntra DP5000 |
|---|---|
| Payload | 500 kg |
| Narrow clearance width | 715 mm |
| Overall frame width | 800 mm |
| Skip | Steel, tipped hydraulically |
| Tipping | Hydraulic, single lever |
|---|---|
| Engine | Single-cylinder OHV petrol |
| Drive | Tracked, walk-behind with handlebar controls |
| Tracks | Rubber |
| Warranty | 2 years parts, 1 year engine (manufacturer-backed) |
Specifications are nominal and may vary slightly by production batch.
Questions
715 mm at its narrowest, on a frame 800 mm across. A standard UK internal door opening is 838 mm and a back door is usually 813 mm, so yes — but measure the frame rather than the door, and watch for a threshold strip that eats the height.
About twelve. A builder's barrow holds roughly 40 kg of wet spoil before it becomes unmanageable. On a 20 metre path that is the difference between an afternoon and a morning.
It is built for it — the photographs on this page are of exactly that. Take slopes straight up or straight down and never across; a tracked machine tips sideways with very little warning once a loose load shifts.
Rubber tracks spread the load far better than wheels, but low ground pressure reduces marking rather than removing it. On soft or newly laid ground, board out a route.
Engine oil and air filter to the engine maker's schedule, track tension checked regularly, and the hydraulic level checked before each session. Ask us for a price and delivery time on tracks and belts.
